SolidPanel

IBS Series – Solid Wall Panels

Introducing the marvel of construction – UAC SolidPanel, your go-to solution for solid wall panels that redefine the standards of structural integrity and aesthetic perfection. Picture a lightweight masterpiece, a sandwiched wall panel that not only guarantees a rock-solid structure but also delivers impeccable wall finishes, ensuring a straight and smooth surface that stands the test of time.

Step into a realm of excellence with UAC SolidPanel, the epitome of IBS panels. Recognised and approved by SIRIM and CIDB, this innovative IBS system doesn’t just meet expectations but exceeds them. Our single wall is 2-hour fire-rated, and we also have a double wall option that’s 4-hour fire-rated. UAC SolidPanel acts like a barrier, reducing outdoor heat from entering your home and keeping it cool and comfortable, especially in hot climates in Malaysia. For sound insulation, UAC SolidPanel has sound insulation up to STC 55dB, which means less noise distraction, better privacy, a more comfortable living space, etc.

But the benefits don’t end there. UAC SolidPanel paves the way for a construction revolution, demanding fewer skilled workers on-site. The outcome? Improved site safety and cleanliness, thanks to the quick and easy installation steps that make construction feel like a breeze.

Embrace the future of construction with UAC SolidPanel – where solid wall panels aren’t just elements; they’re the backbone of reliability and the canvas for your vision. Elevate your projects with a touch of innovation and a whole lot of quality because when it comes to IBS panels, UAC SolidPanel is the undisputed game-changer.

Application

Specification

T75T100
Width (mm)600600
Thickness (mm)75100
Length (mm)2400, 2700, 30002400, 2700, 3000
Weight55kg/m270kg/m2
Fire rated (BS 476 : Part 22 : 1987)2 hours2 hours
Density600 – 700kg/m3600 – 700kg/m3
Sound insulation (ISO 140 – 3 : 1995)STC 36 – 39 dBSTC 40 – 43 dB
